CAT Split Flange 90° Angle Hose End

100R12

HF1XF Dimensions

HnF Part Number Flange Size (inch) Hose ID (inch) A Diameter (inch) B-Drop (inch)
12 Hose – 12FLCAT90 3/4 3/4 1.62 2.50
16 Hose – 16FLCAT90 1 1 1.88 3.00
20 Hose – 20FLCAT90 1-1/4 1-1/4 2.12 3.38
