EPDM Lay-Flat Hose



Application:LF-EPDM

High Pressure, 150 psi, Rubber Lay Flat Hose for General Construction



Construction:

Tube: Black EPDM Rubber

Cover: Black Weather and Ozone-Resistant EPDM Rubber

Reinforcement: High Tensile Textile Cords

Temperature Range: -22°F to 176°F



Hose Assemblies Up To 8 inch are Assembled Using Four 5/8″ 302 Stainless Steel Center Punch Clamps.  Assemblies 8 inch and above uses Four 5/8″ Galvanized Steel Center Punch Clamps.



SKU ID (inch) OD (inch) Working Pressure (psi) Weight / Foot (lbs)
150LF-EPDM 1-1/2 1.81 150 0.36
200LF-EPDM 2 2.32 150 0.50
250LF-EPDM 2-1/2 2.80 150 0.60
300LF-EPDM 3 3.31 150 0.86
400LF-EPDM 4 4.33 150 1.20
600LF-EPDM 6 6.38 150 1.99
800LF-EPDM 8 8.46 150 2.98
1000LF-EPDM 10 10.63 150 5.10

Chemical Resistance
